GIM6010-6

型号 GIM6010-6
品牌 SteadyWin
产品详情

GIM6010-6 安装尺寸图

GIM6010-6 3D模型图



GIM6010-6
驱动板型号(Driver Model)/SDC102SDC301
额定电压(Nominal Voltage)V244824
电压范围(Voltage Range)V12~3612~5612~36
功率(Power)W23322196
额定扭矩(Nominal Torque)N.M3.333
堵转扭矩(Stall Torque)N.M86.929
减速后额定转速(Nominal Speed after Reduce)RPM130513300
减速后最大转速(Max Speed after Reduce)RPM450585400
额定电流(Nominal Current)A9.74.64
堵转电流(Stall Current)A23.539.313.24
相电阻(Phase Resistance)Ω0.550.550.55
相电感(Phase Inductance)mH0.450.450.45
转速常数(Speed Constant)rpm/v18.7512.1916.67
扭矩常数(Torque Constant)N.M/A0.340.730.68
极对数(Number of Pole Pairs)Pairs141414
减速比(Gear Rate)/6:16:16:1
减速器类型(Gear Type)/PlanetaryPlanetaryPlanetary
减速器齿轮材料(Reducer Gear Material)/STEELSTEELSTEEL
减速器齿轮背隙(Reducer Gear Backlash)arcmin151515
电机重量不带驱动(Motor Weight without Driver)g289289289
电机重量带驱动(Motor Weight with Driver)g318318318
电机尺寸不带驱动(Size without Driver)mmØ76*24Ø76*24Ø76*24
电机尺寸带驱动(Size with Driver)mmØ76*35Ø76*35Ø76*35
轴向最大负载(Max Axial Load)N200200200
径向最大负载(Max Radial Load)N800800800
噪音(Noise)dB<60<60<60
通信协议(Communication)/CAN & 485CAN & 485CAN
第二编码器(Second Encoder)/YESYESYES
电机防水防尘等级(Motor Protection Grade)/IP54IP54IP54
工作温度范围(Working Temperature)-20~+80-20~+80-20~+80
板载编码器精度(Resolution of Encoder on Driver)Bit

14

14

14

是否支持单独编码器(Separate Encoder)/NO
NO
NO
是否支持定制抱闸(Custom Brake)/YESYES
YES
