WK5515

Model： WK5515
Brand： SteadyWin
产品详情

WK5515 2D drawing

WK5515 3D model


参数/型号单位WK5515
额定电压(Nominal voltage)V24
额定电流(Nominal current)A1.6
额定扭矩(Nominal torque)N.M0.65
额定转速(Nominal speed)rpm264
最大转速(Max speed)rpm558
堵转扭矩(Stall torque)N.M1.26
堵转电流(Stall current)A3.2
绕线匝数(Winding turns of motor)T42
相间电阻(Interphase resistance)Ω5.62
相间电感(Interphase inductance)Mh3.98
转速常数(Speed constant)rpm/v23
扭矩常数(Torque constant)N.M/A0.43
转子惯量(Rotor inertia)gcm^2456
极对数(Number of pole pairs)Pairs14
工作温度范围(Working temperature)℃-20~80
最高退磁温度(Max demagnetize tempersture)℃120
定子内径(Inner diameter of the stator)mm24
电机尺寸(Motor size)mmØ60*19
电机重量(Motor weight)g196
